10.1" Narrow Bezel PCAP Touch Screen Overlay with ILITEK Touch Controller ILI2511

Brand Name: LB
Model Number: LBCTP101120-9009V1
MOQ: 100pcs
Price: To Be Determined
Packaging Details: Carton Box
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Certification:
CE/ROHS
Aspect Ratio:
16:10
Layers:
Glass On Glass
Touch Sensor:
ITO Technology
Cover Glass:
Chemically Tempered Glass
Resolution:
1920x1200; 1280x800
Transmittance:
>86%
Touch Points:
10 Points Finger Touch
Operating System Support:
Windows, Linux, Android
Supply Ability:
1000pcs Per Day
Product Description

10.1" Narrow Bezel PCAP Touch Screen Overlay with ILITEK Touch Controller ILI2511

Product Description of 10.1" PCAP Touch Screen Overlay:

LBCTP101120-9009V1 is a 10.1-inch projected capacitive touchscreen overlay, which is installed on top of the LCD panel with aspect ratio 16:10 and the resolution is 1920x1200 or 1280x800. The touch controller has standard USB-HID interface, RS232 and IIC for option.


The PCAP Touch Screen product is a cutting-edge technology that offers a versatile and user-friendly touch interface suitable for a wide range of applications. With support for USB, IIC, and RS232 touch interfaces, this product provides seamless connectivity and compatibility with various devices and systems.


Utilizing ITO (Indium Tin Oxide) technology, the touch sensor of the PCAP Touch Screen ensures high sensitivity and accuracy, allowing for precise touch input and smooth operation. This advanced technology enhances the overall user experience by providing a responsive and intuitive touch interface.


When it comes to touch panel technologies, the PCAP Touch Screen stands out with its innovative features and capabilities. Unlike traditional touch panels, such as Surface Acoustic Wave Touch Panel, Infrared Touch Control Panel, or Electromagnetic Touch System, the PCAP Touch Screen offers a modern and efficient touch interface that responds accurately to touch input, providing users with a seamless and engaging interaction experience.

Features of 10.1" PCAP Touch Screen Overlay:

  • Product Name: PCAP Touch Screen
  • Aspect Ratio: 16:10
  • Item: PCAP Touchscreen Overlay
  • Touch Interface: USB, IIC, RS232
  • Resolution: 1920x1200; 1280x800
  • Outline Dimension: 233.53x153.95x2.0mm

Technical Parameters of 10.1" PCAP Touch Screen Overlay:

Resolution 1920x1200; 1280x800
Touch Sensor ITO Technology
Transmittance >86%
Layers Glass On Glass
Operating System Support Windows, Linux, Android
Touch Points 10 Points Finger Touch
Cover Glass Chemically Tempered Glass
Size 10.1 Inches
Item PCAP Touchscreen Overlay
Outline Dimension 233.53x153.95x2.0mm

10.1" Narrow Bezel PCAP Touch Screen Overlay with ILITEK Touch Controller ILI2511 0

Applications:

Product Application Occasions and Scenarios for LB PCAP Touch Screen:


Capacitive Touchscreen Monitor and All-in-one Computer


The LB PCAP Touch Screen, model LBCTP101120-9009V1, is ideal for applications where a high level of accuracy and responsiveness is required, such as interactive kiosks, digital signage, and industrial control panels. The capacitive touch technology provides a smooth and precise touch experience, making it suitable for various professional settings.
