5:4 Ratio 19 Inch Capacitive Multi Touch PCAP Screen With 1280 X 1024 Resolution

Brand Name:	LB
Model Number:	LBCTP190010
MOQ:	50 Pcs
Price:	25~50
Packaging Details:	Carton Box or Wood Case
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Aspect Ratio:

Touch Panel:

Multi Touch PCAP Screen

Viewing Area:

376*301mm

Touch Controller:

ILI2510

Transparency Rate:

Outline Dimension:

395*323mm

Response Time:

Surface Treatment:

Anti-glare Or AF For Option

Supply Ability:

500 pcs per day

Highlight:

19in PCAP Touch Screen

5:4 PCAP Touch Screen

1280 X 1024 pcap touchscreens

Product Description

19-Inch 5:4 Ratio Capacitive Multi Touch PCAP Screen

High-performance 19-inch projected capacitive touch screen with 1280×1024 resolution, delivering exceptional responsiveness and precision for demanding applications.

Product Overview

This advanced PCAP touch screen features highly responsive finger touch detection and multi-touch gesture support, making it ideal for precision applications including graphic design, gaming, and engineering. The ILI2510 touch controller ensures fast, accurate response and natural, intuitive interaction.

Key Features

19-inch screen size with 5:4 aspect ratio
1280×1024 display resolution
Projected capacitive touch technology (PCAP)
Multi-touch gesture support
ILI2510 advanced touch controller
Plug-and-play compatibility with Windows, Android, and Linux
3.9±0.2mm thickness with slim profile
395×323mm outline dimensions
G+G layer construction
2-year touch warranty

Technical Specifications

Surface Treatment	For option, Anti-glare(AG) and Anti-fingerprint(AF)
Touch Resolution	Automatically matches display resolution
Touch Points	Up to 10 points if necessary
Transparency Rate	≥87%
Response Time	10ms
Interface	USB powered and driven

Application Scenarios

This versatile touch screen is engineered for various industrial and commercial applications:

ATM machines
Point of Sale (POS) systems
Open frame machines
Kiosks and interactive displays
Gaming machines
Industrial automation systems
Graphic design and engineering workstations

Customization Options

Model LBCTP190010 supports comprehensive customization services including alternative touch panel technologies such as flush-mount capacitive touch glass and resistive touch panels. Besides:

1. Thickness of Front Glass supports 1.1mm, 2mm, 3mm, 4mm, 5mm, 6mm, 8mm.

2. Surface Treatment: anti-glare and anti-fingerprint

3. Size, Shape, Text and Color supports customization

Support & Services

Our technical support team provides comprehensive assistance including installation, calibration, troubleshooting, and regular software updates. We ensure maximum performance and customer satisfaction with reliable support to minimize downtime and maximize productivity.

Product Details: LBCTP190010| Minimum Order: 100pc | Delivery: 3-20 Working Days | Daily Supply Capacity: 500pcs
